Description
TAURUS 4047 ALUMINIUM ELECTRODES
The TAURUS 4047 aluminum welding electrode contains approximately 12% silicon making it a popular choice for welding aluminum alloys, particularly those with high silicon content. TYPICAL WELD DEPOSIT VALUES % Silicon Aluminum Copper Chromium 12% 87.7% 0.20 % 0.30 % It is known for its good fluidity and crack resistance, making it suitable for various applications in industries such as automotive, aerospace, and marine.
The TAURUS 4047 welding rod is typically used for welding aluminum to aluminum, as well as for repairing aluminium-silicon and aluminium-magnesium-silicon cast parts.
For optimum performance, during he welding process the electrode should be used perpendicular to the workpiece with a short arc length. When the workpiece thickness exceeds 10m, preheating between 150°C and 250°C should be applied. Slag residues cause corrosion and must therefore be removed completely from the weld bead.
The Taurus 4047 electrodes are supplied in a vacuum packed tin and must be stored in a dry location. Electrodes can be redried if required before use.
SOME FEATURES AND BENEFITS
- Supplied in a vacuum packed tin.
- Approximately 12% silicon.
- Good fluidity and crack resistance.
POLARITY
- DCEP (DC Electrode Positive)
WELDING POSITIONS
- Flat
- Horizontal
- Vertical up
CLASSIFICATIONS
- AWS/ASME SFA-5.3:E4047
- EN ISO 18273:E Al 4047 (AlSi 12)
| TYPICAL WELD DEPOSIT VALUES | % |
| Silicon | 12% |
| Aluminium | 87.7% |
| Copper | 0.20 % |
| Chromium | 0.30 % |
| TYPICAL MECHANICAL VALUES | AS WELDED |
| Yield strength (N/mm²) | 80 |
| Tensile strength (N/mm²) | 200 |
| Elongation A5(%) | 8 |
